PET Bottle Blow Molding Machine, Stainless Steel
Short Description
Model No.: Hits: 9
PET Bottle Blow Molding Machine Provider: Blow Molding Machine for Plastic PET Containers & Bottles in All Shapes, Full Automatic, 6 Cavity, CE, SGS, ISO 9001.
Request a quoteTags:
Key Specifications / Features
PET Bottle Blow Molding Machine
1. Full automatic
2. 6 cavity
3. Touch screen, PLC, easy operate and maintain
4. CE, SGS, ISO 9001
5. Materials: stainless steel
Product Description:
This stretch blow molding machine is suitable for producing plastic containers and bottles in all shapes. It is widely used to produce carbonated drink bottles, mineral water bottles, pesticide bottles, oil bottles, cosmetics, wide-mouth bottles and hot filling bottles and so on. Automatic preform feeding system. Infrared oven heater. The fully automatic process with low investment, high efficiency, quick and safe operation, easy for trouble-shooting, maintenance and other benefits. Stable performance with advanced PLC. Automatic preform conveyer to save human cost. Preform self-rotation and infrared pre-heater revolution assure the even distribution of heat, which improves the bottle shaping rate, increases production.
Detailed images:
Technical parameter:
Application:
This bottle blowing machine is for blowing PET performers into a PET bottle.
1. Full automatic
2. 6 cavity
3. Touch screen, PLC, easy operate and maintain
4. CE, SGS, ISO 9001
5. Materials: stainless steel
Product Description:
This stretch blow molding machine is suitable for producing plastic containers and bottles in all shapes. It is widely used to produce carbonated drink bottles, mineral water bottles, pesticide bottles, oil bottles, cosmetics, wide-mouth bottles and hot filling bottles and so on. Automatic preform feeding system. Infrared oven heater. The fully automatic process with low investment, high efficiency, quick and safe operation, easy for trouble-shooting, maintenance and other benefits. Stable performance with advanced PLC. Automatic preform conveyer to save human cost. Preform self-rotation and infrared pre-heater revolution assure the even distribution of heat, which improves the bottle shaping rate, increases production.Detailed images:
Technical parameter:
| TIEM | UNIT | SGB-3-1500 | SGB-4-1500 | SGB-6-1500 | SGB-2-5000 |
| Theoretical output | PCS/H | 3300 | 4500 | 6500 | 1800 |
| Volume | L | 1.5 | 1.5 | 1.5 | 5 |
| Max.height | mm | 360 | 360 | 360 | 360 |
| Max.diameter | mm | 105 | 105 | 105 | 195 |
| Number of cavities | / | 3 | 4 | 6 | 2 |
| Mold plate dimension | mm | 430*360 | 600*360 | 820*360 | 820*360 |
| Mould thickness | mm | 190 | 190 | 190 | 280 |
| Mould opening stroke | mm | 110 | 110 | 110 | 200 |
| Power | 220-380 | 220-380 | 220-380 | 220-380 | |
| Total power | kw | 18 | 25 | 35 | 25 |
| Heating power | kw | 15 | 22 | 32 | 22 |
| Operation Pressure | mpa | 0.8-1.0 | 0.8-1 | 0.8-1 | 0.8-1 |
| Action Air Consuming | m³/min | >1.6 | >1.6 | >2 | >1.6 |
| Blowing Pressure | Mpa | 2.6-3.0 | 2.6-3.0 | 2.6-3 | 2.6-3 |
| Blowing air consuming | m³/min | >2.4 | >3.2 | >4.8 | 3.4*1.9*2 |
| Main body dimension | M | 2.7*1.45*2.0 | 3.4*1.9*2 | 4.4*1.9*2 | 3.4*1.9*2.1 |
| Main body weight | KG | 2000 | 2600 | 3200 | 2600 |
| Preform autoload | M | 1.6*0.85*2.2 | 1.6*0.85*2.2 | 1.6-0.85-2.2 | 1.6*0.85*2.2 |
| Preform autoloader weight | KG | 200 | 200 | 200 | 200 |
Application:
This bottle blowing machine is for blowing PET performers into a PET bottle.
